PE-connector / DIN-rail terminal 2-conductor green-yellow, ONKA, manufactured in Turkey

ONKA's compact installation connector provides good opportunities to connect all wires with different cross-sections. The transparent housing makes it easy to check the correct placement of the wires. The original ONKA quick connectors are easy to install and provide 100% connection security.

Technical parameters

Cross-section of the connected single wire up to: 35mm2
Color: Green-yellow (camouflage)
Insulation material in the main housing: polyamide (PA6.6)
Contact/bridge material: CK45 steel/copper
Tightening torque: 1.2 Nm
Connection position: lateral/side
Length of cable strip: 16 mm
Electrical connection type: screw terminal
Nominal voltage: 750V
Operating temperature range: -40°C... 140°C
Mounting method: DIN rail 35 mm
Standard: EN-60947-7-1
